Product Details
The Honeywell 51202329-300, also cataloged as the 51202329 Series C I/O Link Cable, operates as a dedicated hardware component for high-speed multi-drop signal transmission within Experion PKS C300 and Series C I/O platforms.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 51202329-300 |
| Brand | Honeywell |
| Origin | USA |
| Weight | 0.1 kg |
| Dimensions | 3 meters (nominal length) |
| Operating Temp | -40 deg C to +85 deg C |
| Power Consumption | Passive component (30 VDC rated voltage) |
| Cable Type | Shielded multi-core communication cable |
| Drop Configuration | 3 drops (supports two CF9s, two C300s, one 6-inch I/O module) |
| Connector Type | Factory-installed system-specific I/O Link connectors |
| Shielding | Foil shielded for EMI protection |
| Jacket Material | PVC (UL 94V-0 flame rated) |
Channel-to-Channel Isolation & Signal Integrity
The 51202329-300 communication assembly ensures signal preservation across distributed Series C I/O topologies. Integrating channel-to-channel isolation principles across the local I/O link bus, the cable structure isolates process controller communication channels from transient ground loops and differential common-mode noise. High-density foil shielding limits cross-talk and electromagnetic interference (EMI) during high-frequency data exchanges between C300 controllers, CF9 modules, and local I/O carrier bases.
Frequently Asked Questions
Q: What is the maximum voltage rating for the 51202329-300 cable assembly?
A: The cable is insulation-rated for a maximum operating voltage of 30 VDC across all internal conductor pairs.
Q: Does the 51202329-300 cable support hot-swapping during active I/O bus operation?
A: Yes, physical connection or disconnection of the drop connectors can occur without removing system power, provided proper grounding practices are observed during insertion.
Field Installation Guidelines
- Ensure the control cabinet channel trays are clean and free of sharp metal edges before routing the cable assembly.
- Maintain a minimum bend radius of at least 10 times the outer cable diameter during installation to prevent internal foil shield tearing or conductor strain.
- Secure the factory-installed connectors firmly into the targeted C300 or CF9 carrier ports until the retaining clips engage completely.
- Route the I/O link drop cable through dedicated low-voltage trunking, maintaining separate pathways from high-voltage AC power wiring and motor lead conduits.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
